Project Gallery

A single project's image gallery, with a lightbox. Like every block in the library, it is a second authoring surface, not a second renderer: the canvas preview and the front end are both produced by the Project Gallery element — the same server-side code as the page builder — so the output is identical either way.

Options

Select the block and open the Settings (block) tab; the whole sidebar is generated from the element's option schema, so it stays in step with the page builder.

Option	What it does
Project (project_id)	Which project's gallery to show (defaults to the current project in a single-project template).
Layout (columns, columns_tablet, columns_mobile, gap, ratio, image_size)	Responsive columns, spacing and image crop.
Lightbox + Captions (lightbox, captions)	Open images full-size, and show captions.

The block also opts into WordPress Margin / Padding (and, where it makes sense, alignment), which inherit the site's design system from theme.json.

:::note Needs the Portfolio extension This block reads Projects — the custom post type the Portfolio extension registers. Activate it, add a project or two, and fill in their details. :::

Sample content

A block stores only what you change as one upOptions object; the element's declared defaults fill in the rest at render time. The demo above is:

<!-- wp:unysonplus/project-gallery {"upOptions":{"project_id":"272","columns":"2"}} /-->

The project gallery element

The block and the page builder's Project Gallery element are two doors onto the same code. Its full option, markup and behaviour reference is documented there.
